Product Advantages
● High precision & long-term stability, no drift in long-time operation
● Standard 4-20mA output, compatible with most industrial control systems
● 316L stainless steel probe, excellent corrosion & wear resistance
● Compact rod-shaped structure, easy installation in narrow space
● Wide pressure range, applicable for liquid, gas and steam media
● Strong anti-interference and shockproof capability, fit harsh working conditions
● Low failure rate, maintenance-free design, save after-sales cost
● Cost-effective with reliable industrial grade quality
Introduction
Technical Parameters
Video
Design Features
Main Functions and Application Scenarios
High measurement accuracy, stable and reliable performance
4-20mA standard signal output, easy system connection
316L stainless steel material, corrosion resistant
Compact rod type design, easy installation and space saving
Wide measuring range, suitable for liquid, gas and steam
Good shock and vibration resistance, adapt to harsh industrial environment
Long service life, low maintenance cost
Measuring Range
0-1.6Mpa
Accuracy Class
0.075
Thread Size
G:M20×1.5
|
Typical application |
Liquid, gas, steam |
|
Product model |
NP-93420-IB |
|
Pressure measuring range |
0-1.6Mpa |
|
Diaphragm material |
316L |
|
Accuracy class |
0.075 |
|
Power supply |
24VDC |
|
Signal output |
4~20mA+HART |
|
Ambient temperature |
-40+85 ℃ |
|
Process temperature |
0-100℃ |
|
Thread size |
G:M20×1.5 |
|
Damping time |
0.1 - 16s adjustable |
|
Overload allowed |
≤2 times the rated range |
|
Live display |
LCD |
|
Protection grade |
IP67 |
|
Explosion - proof grade |
Exia II CT6 Ga, Exd II CT6 Gb |
Main Functions
Real-time detect and measure liquid, gas and steam pressure.
Convert pressure signal into standard 4-20mA electrical signal output.
Continuously monitor industrial pipeline and equipment pressure status.
Support remote signal transmission for PLC and DCS control system.
Overpressure protection and stable pressure data collection.
Adapt to various industrial working conditions for automatic process control.
Application Scenarios
Petroleum, chemical and petrochemical industry
Water treatment and sewage pipeline monitoring
Hydraulic and pneumatic system pressure detection
Boiler, steam and thermal energy engineering
Food, beverage and pharmaceutical production process
Metallurgy, mining and industrial automation control
HVAC and central air conditioning system
Machinery manufacturing and pipeline pressure monitoring
Application Scope
Suitable for pressure measurement of gas, liquid and steam media.
Pressure monitoring for industrial pipelines, tanks, boilers and water treatment systems.
Widely used in petrochemical, metallurgy, mining, HVAC, food and pharmaceutical automation.
Real-time online pressure detection for hydraulic, pneumatic and mechanical equipment.
Notes
Avoid strong vibration, impact and high temperature radiation during installation.
Do not operate beyond the measuring range for a long time to prevent sensor damage.
Ensure medium is compatible with wetted material to avoid corrosion.
Wire strictly according to marks, avoid positive and negative connection reversal.
Install vertically or horizontally in standard way to ensure measurement accuracy.
Do not install in close distance with strong electromagnetic interference sources.
Check sealing and wiring regularly to prolong service life.
