Side - Mounted Magnetic Flap Level Gauge for Liquid Level Measurement at Normal Temperature and Pressure
Empowering Global Industry with Advanced Precision Technology
Clear visual display, liquid level can be observed from a long distance.
Simple structure, stable performance and long service life.
Good sealing performance, leak-proof and safe for various liquids.
Wide range of application, compatible with high temperature and high pressure working conditions.
Optional remote signal output for automatic control system.
Easy installation and basically maintenance-free during use.
Introduction
Technical Parameters
Video
Design features
Product Features and Model Parameters
Intuitive full-view display, readable from far and wide angles.
Magnetic coupling design, no direct contact between internal and external parts.
Excellent sealing property, safe and leak-proof.
Adaptable to high temperature, high pressure and various media.
Optional alarm switch and remote transmission function.
Simple installation, stable operation and low maintenance.
Main material
304
Measuring range
0-1m
Process connection
DN25 Flange
| Typical application | Liquid level measurement |
| Product model | NYUHZ |
| Installation form | Side mounted |
| Main material | 304 |
| Measuring range | 0-1m |
| Measuring accuracy | ±0.5mm |
| Medium density | ≥0.45g/cm³ |
| Density difference | ≥0.1g/cm³ |
| Medium viscosity | ≤0.4Pa.S |
| Control output | 220VAC,1A |
| Transmit output | 4...20mA (power supply 24VDC) |
| Process temperature | 0～100℃ |
| Process pressure | 0～1.6MPa |
| Process connection | DN25 Flange |
| Resolution | ±1mm |
| Protection class | IP67 |
| Explosion-proof grade | Exia II CT6 Ga, Exd II CT6 Gb |
Main Functions
Visually display real-time liquid level inside tanks and vessels.
Support upper and lower limit alarm to avoid overfilling or liquid shortage.
Optional remote signal output for centralized monitoring and automatic control.
Continuously track liquid level changes for safe production.
Adapt to various working conditions to realize long-term stable level measurement.
Application Scenarios
Petroleum, chemical and petrochemical industries
Power plants and heating systems
Water treatment and environmental protection projects
Food, beverage and pharmaceutical factories
Metallurgy, machinery and light industry
Storage tanks, reactors and various pressure vessels
Application Scope
The magnetic flap level gauge is used for liquid level measurement and indication of tanks, reactors and pressure vessels. It suits water, oil and various chemical liquids, and is widely applied in petroleum, chemical, power, water treatment, food, pharmaceutical and other industrial fields.
