Durable Electromagnetic Flow Meter for Slurry Sewage and Industrial Fluids
Empowering Global Industry with Advanced Precision Technology
Product Advantages
No pressure loss inside the pipe, low energy consumption for fluid delivery
No movable wear parts, long service life and minimal maintenance
High measurement accuracy, unaffected by temperature, pressure and viscosity changes
Wide adaptability, suitable for conductive liquids including slurry and corrosive fluid
Multiple liner & electrode material options for strong anti-corrosion performance
Stable measuring performance under strong vibration and harsh industrial environments
Bi-directional flow measurement supported
Rich signal output modes for easy connection with PLC and DCS
Simple installation, straight pipe requirement is relatively low
Optional explosion-proof and IP68 waterproof models for outdoor & hazardous areas
Introduction
Technical Parameters
Design features
Product Features and Model Parameters
Electromagnetic induction measurement principle, no internal moving components
Zero pressure loss, saving pipeline operating energy
Compatible with all conductive liquids, slurries and corrosive media
Multiple lining and electrode materials for anti-corrosion & wear resistance
Bidirectional flow measurement function
Built-in digital signal processing, strong anti-interference capacity
Multiple signal outputs to connect PLC, DCS control systems
Optional explosion-proof and high waterproof grade for harsh sites
Local LCD display showing flow rate, totalizer and status data
Low maintenance, long service lifespan
Pipe Size
DN250
Output
4-20mA +RS485
Supply power
220VAC
| Mearsurment Meduim | Water |
| Flow Range | 90-900m3/h |
| Accuray | 0.5% |
| Pipe Size | DN250 |
| Output | 4-20mA +RS485 |
| Supply power | 220VAC |
| Lining material | PO |
| Electrode material | 316L |
| Process connection | HG/T20592-2009 DN250 PN16 CS |
| Pressure | 1.6Mpa |
| Temperature | -20--80℃ |
| Display | LCD |
Main Functions
Continuous online measurement of volumetric flow of conductive liquids
Real-time display of instantaneous flow and cumulative total flow
Bidirectional flow detection for forward and reverse fluid monitoring
Transmit flow data via analog/digital signals to PLC and DCS
Alarm prompt for empty pipe, low conductivity and abnormal flow status
Application Scenarios
Water treatment: Tap water, sewage, wastewater and sludge pipeline flow monitoring
Chemical industry: Acid, alkali, salt solution and corrosive liquid metering
Metallurgy & mining: Slurry, mineral pulp flow measurement
Food & pharmaceutical: Sanitary liquid such as beverage, syrup and liquid medicine
Paper industry: Pulp flow metering
Petrochemical: Conductive process fluid pipeline flow control
Municipal engineering: Urban water supply and drainage pipeline flow statistics
